New Power ND6

ROPS

The most fuel efficient dozer Hydrostatic travel drive with electronic control Shangchai engine with CATERPILLAR pedigree (optional Cummins) were developed for the most demanding conditions of use. Their low rated speed ensures high operational reliability and a long lifetime. Model ND6 Engine model SDEC SC9DK190G3 Rated power(kw/rpm) 147/1700 kw/rpm Displacement(L) 8.8 Max.torque(N.m/rpm) 920/1400 Operating weight(Kg) 19575 Dimension(no ripper)(mm) 4175*2440*3400 Min ground clearance(mm) 390 Ground pressure(MPa) 0.65 kg/cm2 Track shoe width(mm) 560 Track gauge(mm) 1880 Dozing capacity( m³) 5.65 Blade width(mm) 3160 Blade height(mm) 1410 Max drop below ground(mm) 473 Pitch(mm) 203 Quantity of track link 39 Max pressure(MPa) 26MPa Grade ability(°) 30 Forward(km/h) 4.8/7.8/11 Reverse(km/h) 4.8/7.8/11Materials and specifications are subject to change without notice
