SEM 656F

Preis ohne MwSt.

FavoriteFavoriten
shareTeilen
Save searchSuche speichern
Drucken

INFO

Produktgruppe
Radlader
Marke / Model
SEM 656F
Baujahr
2024
Betriebsstunden
2.000 Std.
Zustand
Generalüberholt,Aufbereitet
Land
China
Allgemeine Bewertung
1
2
3
4
5
Mascus ID
24FBDD7F

PREISANGABE

Währung auswählen

DETAILS

Lagernummer
QFSEM010
Typ
Diesel
Dienstgewicht
17.385 kg
Max. Traglast
5.500 kg
Type opbouw
Fester Rahmen
Kabinentyp
Geschlossene Kabine
Motor
WD10G220E23
Schaufelvolumen
5 m3
Motorleistung
162 kW (220 PS)
Transportabmessungen (L x B x H)
8472 x 3117 x 3465 mm
Originalfarbe
yellow
Produktionsland
China
Lieferbedingungen
FOB, CIF
Zertifikate
EPA, CE, TÜV
Zubehör
Autom./hydraulische Schnellkupplung
GPS
Skeletteimer
Standard Tieflöffel
Zusätzliche Informationen
Model Model SEM 656F Main Specifications Rated Load 5,500kg Operating Weight with Standard Bucket 17,385kg Bucket Capacity 2.6-5m³ Wheel Base 3,350mm Overall Dimension 8,472*3,117*3,465mm Max. Drawbar Force 170kN Breakout Force 161kN Dump Clearance 2,991mm B-Pin Height 4,162mm Transmission Transmission Type Countershaft, power shift Transmission Gears F4/R4 Torque Converter Type Single stage, 3 elements Forward I/Reverse I 7.6/7.6 Forward II/Reverse II 14/14 Forward III/Reverse III 22/22 Forward IV/Reverse IV 39/39 Maker & Type TR200 Axle (Axle, Tire & Brakes) Main Drive Type Spiral bevel gear, single stage Final Drive Reduction Type Planetary type, single stage Rear- oscillation +/- ±11 Engine Engine Model WD10G220E23 Rated Power 162kW Rated Speed 2,000r/min Displacement 9.7L Implement Hydraulic System Implement System Type Open center flow sharing Boom Raise Time 5.13s Hydraulic Cycle Time 9.3s System Pressure Setting 17MPa Brake System Service Brake Dry&caliper, air to oil control Parking Brake Drum/Shoe Steering System System Type Load sensing Steering Pump Type Gear pump System Pressure Setting 16MPa Steering Angle (L/R) 38±1 Tires Size 23.5-25 Type Bias Layer 16 Textured Type L-3

Achieve Innovations

5F Building 4, No.28, (M) Fuyuan Road, Kaifu Dist 410003 Changsha Hunan 湖南 China
